SANY SR185‑C10 Rotary Drilling Rig – Deep Foundation Power Adapted for AUSTRALIAN Conditions
The SANY SR185‑C10 is a heavy-duty rotary drilling rig purpose built for mid-to-deep piling work, making it an excellent match for Australia’s infrastructure and civil construction demands. Combining high capacity and efficiency in a manageable footprint, it serves a broad array of foundation needs across urban developments, transport projects, and large scale commercial builds.
Key Strengths:
-
Impressive drilling capabilities: Supports pile diameters up to 1.8 m and depths of 59 m (via friction Kelly bar) or 47 m (interlocking bar) .
-
Powerful performance specs: Equipped with an ISUZU 6HK1 EFI engine delivering 212 kW @ 2000 rpm, supported by a main winch capacity of 185 kN and rotary torque up to 190 kN·m for robust drilling action.
-
Stability-first chassis design: Features a telescopic wide-spread undercarriage with large-diameter slewing bearings, ensuring precise vertical operation even in deep bore scenarios.
-
Efficiency and fuel savings: Employs power optimisation technology to dynamically fine-tune engine-hydraulic output, optimising fuel use and reducing operational costs .
-
Rugged build for reliability: Boasts a box structure mast and sixth-generation Kelly bar – delivering a 25% durability boost ideal for weathered rock formations.
-
Smart, operator-friendly interface: Comes standard with a 10″ HD touchscreen console and user-centric enhancements like remote monitoring, ensuring greater control and productivity.
-
AU-ready transport dimensions: With an operating weight of 63 t, transport width of 3.21 m, and overall height of 21 m, it’s designed for efficient movement between sites via local haulage.
The SR185‑C10 combines power, precision, and practicality in a package well-suited to the rigours of Australia’s foundation engineering sector – making it a compelling choice for contractors and infrastructure projects seeking dependable deep drilling performance.
